Nguyen Fittings and Plates, located in Da Nang, Vietnam, is a reputable manufacturer and supplier of **Super Duplex Steel UNS S32760 Forged Fittings**. These fittings are specifically designed for industrial piping systems that face high pressure and corrosive environments. They ensure secure, leak-proof connections while boasting impressive mechanical strength, excellent resistance to pitting, crevice, and stress corrosion, along with remarkable dimensional stability. Crafted through precision forging, controlled machining, and stringent quality checks, Nguyen Fittings guarantees smooth internal surfaces, consistent wall thickness, and durability that lasts. These fittings are utilized across various sectors, including chemical processing, oil and gas, petrochemical, marine, desalination, and power generation, all while adhering to international standards for safe and reliable operation in critical piping systems.
Specifications : ASTM A182 / ASME SA182
Size: 1/2″NB TO 4″ NB IN
Class : 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc.
Type: Socket Weld (S/W) and SCREWED (SCRD) – NPT, BSP, BSPT, Threaded Fittings.
Super Duplex Steel UNS S32760 Forged Fittings are composed of a high-alloy duplex stainless steel that includes chromium, nickel, molybdenum, and nitrogen. This distinctive blend results in a dual-phase microstructure (austenite + ferrite), which provides exceptional mechanical strength and superior corrosion resistance compared to standard austenitic stainless steels. These fittings are particularly resistant to chloride-induced stress corrosion cracking, pitting, and crevice corrosion, while also maintaining excellent toughness, ductility, and stability under high pressure and temperature conditions.
| UNS | C | Si | Mn | P | S | Cr | Mo | Ni | N |
| S32760 | 0.030 | 0.80 | 1.20 | 0.035 | 0.020 | 24.0/26.0 | 3.0/5.0 | 6.00/8.00 | 0.24/0.32 |
| UNS | Grade | Proof Stress 0.2% (MPa) | Tensile Strength (MPa) | Elongation A5(%) | Hardness Max | |
| HB | HRB | |||||
| S32760 | 2760 | 550 | 795 | 15 | 310 | 32* |
Nguyen Fittings is a leading supplier of Super Duplex Steel UNS S32760 Fittings in Da Nang, Vietnam. We offer an extensive range of Super Duplex Steel UNS S32760 Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Standard | Super Duplex S2760 |
| UNS | S32760 |
| WERKSTOFF NR. | 1.4410 |
Choose Super Duplex Steel UNS S32760 Forged Fittings from Nguyen Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Super Duplex Steel UNS S32760 forged fittings offer several advantages, including exceptional corrosion resistance to chloride-induced stress corrosion cracking, pitting, and crevice corrosion. Their high tensile strength and excellent toughness make them ideal for use in harsh environments, such as offshore, marine, and chemical industries. These fittings are also highly resistant to erosion, ensuring durability and extended service life. Their ability to perform reliably in extreme temperatures and pressures makes them a preferred choice for critical applications, providing long-term performance and cost-efficiency in demanding industries.
Yes, custom sizes for Super Duplex Steel UNS S32760 Forged Fittings are available at Nguyen Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@nguyenfittings.com
| NPS (Normal Pipe Size) | O.D. (Outside Daimeter) | Elbow 90 Deg | Elbow 45 Deg | Return Elbow 180 Deg | ||||
|---|---|---|---|---|---|---|---|---|
| (inch) | Long Radius Elbow | Short Radius | Long Radius Elbow | Long Radius Elbow | ||||
| (millimeter/ MM) | (inch./ Inches) | Center to Face (Inches) | Center to Face (Inches) | Center to Face (Inches) | Radius (Inches) | Center to Center (Inches) | Back to face (Inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | – | 7/16 | 2 1/4 | 1 11/16 | |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
| DN (Normal Pipe Size) For ASME B16.9 | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | Elbow 90 Deg | Elbow 45 Deg | B16.9 Equal Tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
SS UNS S32760 Forged Fittings find extensive application in offshore oil and gas platforms, seawater desalination plants, chemical reactors, pulp and paper processing, and high-pressure pipelines that transport corrosive fluids. They are perfect for situations that require both high mechanical strength and resistance to harsh corrosive environments, especially in chloride-rich settings. The blend of durability, corrosion resistance, and fabrication versatility makes Super Duplex Steel UNS S32760 Forged Fittings a top choice for many industries.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
