Carbon Steel Pipe Fittings Manufacturer and Supplier in Da Nang, Vietnam

Nguyen Fittings and Plates is a leading manufacturer and supplier of Carbon Steel Pipe Fittings in Da Nang, Vietnam, designed for high-strength and cost-effective piping systems. These fittings comply with ASTM A234 WPB, ASME B16.9, and MSS-SP-75 standards. Known for excellent weldability, durability, and toughness, carbon steel fittings include elbows, tees, reducers, and caps.

Carbon Steel Pipe Fittings Price List in Da Nang, Carbon Steel Pipe Fittings Supplier in Hue, Carbon Steel Pipe Fittings Exporter in Hanoi, Carbon Steel Pipe Fittings Supplier in Hanoi, Carbon Steel Pipe Fittings Exporter in Sapa, Carbon Steel Pipe Fittings Size Chart, Carbon Steel Pipe Fittings Price in Ho Chi Minh, Carbon Steel Pipe Fittings in Da Nang, Carbon Steel Pipe Fittings Supplier in Vietnam, Carbon Steel Pipe Fittings Stockist in Hue, Carbon Steel Pipe Fittings Exporter in Vietnam

Carbon Steel Pipe Fittings Specification

Grade Specification	Carbon Steel: ASTM/ASME A234 WPB / A860 – MSS-SP-75 WPHY 42 / 46 / 52 / 56 / 60 / 65 / 70Low temperature Steel: A420 WPL3 / A420 WPL6
Type	Seamless / Welded / Fabricated
Bending Radius	R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Range	½”NB to 48″NB in Sch 10s, 40s, 80s, 160s, XXS.
Dimensions	ANSI/ASME B16.9, B16.28, MSS-SP-43.

Carbon steel pipe fittings primarily contain carbon (up to 0.30%), manganese, phosphorus, sulfur, and iron. These fittings offer tensile strength of 415–585 MPa, yield strength ≥240 MPa, and good ductility and impact resistance. The material is heat-treated (normalized or stress relieved) to improve performance in pressure-bearing systems. Carbon steel is known for its machinability, good weldability, and lasting mechanical integrity, making it a preferred choice for structural and pressure piping environments.

Carbon Steel Pipe Fittings Chemical Compostion

Element	Weight %
Carbon	0.08 – 0.15
Nickel	0.5 max
Phosphorus	0.025 max *
Sulphur	0.025 max *
Molybdenum	0.90 – 1.10
Chromium	2.00 – 2.50
Silicon	0.15 – 0.50
Manganese	0.30 – 0.60

Carbon Steel Pipe Fittings Mechanical Properties

Property	Values
Hardness	197 – 237 BHN (75 Ksi min)
Ultimate Tensile Strength *	95 min Ksi (655 Mpa)
Elongation *	17 % min
Reduction of Area *	35 % min
0.2 % Yield Strength *	75 min Ksi (517 Mpa)
Charpy Impact Toughness	42 mean/ 33 min J at –18o C

Carbon Steel Pipe Fittings Exporter in Hue, Carbon Steel Pipe Fittings Sizes in mm, Carbon Steel Pipe Fittings Manufacturer in Hanoi, Carbon Steel Pipe Fittings Thickne Alloy Steel Weld Neck, Carbon Steel Pipe Fittings Supplier in Da Nang, Carbon Steel Pipe Fittings Price List in Vietnam, Carbon Steel Pipe Fittings Distributor in Sapa, Carbon Steel Pipe Fittings Supplier in Hanoi, Carbon Steel Pipe Fittings Distributor in Vietnam

Largest Carbon Steel Pipe Fittings Supplier in Da Nang, Vietnam

Nguyen Fittings is a leading supplier of Carbon Steel Pipe Fittings in Da Nang, Vietnam. We offer an extensive range of Carbon Steel Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Carbon Steel Pipe Fittings from Nguyen Fittings?

Choose Carbon Steel Pipe Fittings from Nguyen Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.

Carbon Steel Pipe Fittings Exporter in Hue, Carbon Steel Pipe Fittings Sizes in mm, Carbon Steel Pipe Fittings Manufacturer in Hanoi, Carbon Steel Pipe Fittings Thickne Alloy Steel Weld Neck, Carbon Steel Pipe Fittings Supplier in Da Nang, Carbon Steel Pipe Fittings Price List in Vietnam, Carbon Steel Pipe Fittings Distributor in Sapa, Carbon Steel Pipe Fittings Supplier in Hanoi, Carbon Steel Pipe Fittings Distributor in Vietnam

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Carbon Steel Pipe Fittings offer several advantages, making them a preferred choice across industries. They provide exceptional strength and durability, allowing them to withstand high pressures and heavy loads. These fittings are highly resistant to wear and impact, ensuring longevity in demanding conditions. Cost-effectiveness is another key benefit, as carbon steel is less expensive compared to other alloys while maintaining excellent performance. Their adaptability to various temperatures and resistance to corrosion in moderate environments make them versatile for numerous applications, including oil and gas, construction, and power generation industries.

Types of Carbon Steel Pipe Fittings

Are Custom Sizes Available for Carbon Steel Pipe Fittings?

Yes, custom sizes for Carbon Steel Pipe Fittings are available at Nguyen Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@nguyenfittings.com

Carbon Steel Pipe Fittings Dimensions

NPS (Normal Pipe Size)	O.D. (Outside Daimeter)		Elbow 90 Deg		Elbow 45 Deg		Return Elbow 180 Deg
*(inch)*			Long Radius Elbow	Short Radius	Long Radius Elbow		Long Radius Elbow
	*(millimeter/ MM)*	*(inch./ Inches)*	Center to Face (Inches)	Center to Face (Inches)	Center to Face (Inches)	Radius (Inches)	Center to Center (Inches)	Back to face (Inches)
1/2	21.3	0.840	1 1/2	–	5/8		2	1 7/8
3/4	26.7	1.050	1 1/8	–	7/16		2 1/4	1 11/16
1	33.4	1.315	1 1/2	1	7/8		3	2 3/16
1 1/4	42.2	1.660	1 7/8	1 1/4	1		3 3/4	2 3/4
1 1/2	48.3	1.900	2 1/4	1 1/2	1 1/8	3	4 1/2	3 1/4
2	60.3	2.375	3	2	1 3/8	4	6	4 3/16
2 1/2	73.0	2.875	3 3/4	2 1/2	1 3/4	5	7 1/2	5 3/16
3	88.9	3.500	4 1/2	3	2	6	9	6 1/4
3 1/2	101.6	4.000	5 1/4	3 1/2	2 1/4	7	10 1/2	7 1/4
4	114.3	4.500	6	4	2 1/2	8	12	8 1/4
5	141.3	5.563	7 1/2	5	3 1/8	10	15	10 5/16
6	168.3	6.625	9	6	3 3/4	12	18	12 5/16
8	219.1	8.625	12	8	5	12	24	16 5/16
10	273.1	10.750	15	10	6 1/4	15	30	20 3/8
12	323.9	12.750	18	12	7 1/2	18	36	24 3/8

Carbon Steel Pipe Fittings Weight Chart

DN (Normal Pipe Size) For ASME B16.9	Schedule 10S			Schedule 40S			Schedule 80S
DN (Normal Pipe Size) For ASME B16.9	Elbow 90 Deg	Elbow 45 Deg	B16.9 Equal Tee	Elbow 90 Deg	Elbow 45 Deg	B16.9 Equal Tee	Elbow 90 Deg	Elbow 45 Deg	B16.9 Equal Tee
8	0.02	0.01	0.03	0.03	0.02	0.06	0.04	0.03	0.07
10	0.03	0.02	0.05	0.03	0.02	0.03	0.06	0.04	0.09
15	0.06	0.03	0.09	0.08	0.04	0.10	0.10	0.05	0.14
20	0.07	0.03	0.13	0.08	0.04	0.17	0.11	0.05	0.20
25	0.14	0.08	0.28	0.15	0.11	0.29	0.22	0.14	0.38
32	0.23	0.11	0.49	0.26	0.17	0.59	0.40	0.23	0.68
40	0.30	0.17	0.68	0.40	0.23	0.86	0.51	0.29	1.02
50	0.50	0.25	0.85	0.70	0.4	1.28	0.91	0.59	1.59
65	0.85	0.48	1.41	1.40	0.77	2.19	1.81	0.99	3.13
80	1.25	0.63	1.77	2.20	1.08	3.31	2.97	1.50	4.45
90	1.70	0.75	2.67	2.83	1.42	4.08	4.00	2.00	5.44
100	2.10	1.08	3.46	4.47	2.09	5.27	6.18	2.81	7.71
150	5.45	2.72	8.07	10.89	5.44	10.99	16.32	8.16	13.61
200	10.20	5.33	15.65	21.54	10.77	20.91	33.11	16.56	28.12
250	18.15	9.75	26.46	38.56	19.27	35.38	51.71	25.86	49.90
300	25.80	13.62	39.46	59.42	29.71	62.14	79.38	39.69	83.91

Carbon Steel Pipe Fittings Supplier in Da Nang, Carbon Steel Pipe Fittings Weight Chart, Carbon Steel Pipe Fittings Exporter in Hue, Carbon Steel Pipe Fittings Manufacturer in Hanoi, Carbon Steel Pipe Fittings Price List in Vietnam, Carbon Steel Pipe Fittings Sizes in mm, Carbon Steel Pipe Fittings Distributor in Sapa, Carbon Steel Pipe Fittings in Ho Chi Minh, Carbon Steel Pipe Fittings Distributor in Vietnam

Application Industry of Carbon Steel Pipe Fittings

Carbon Steel Pipe Fittings are used in oil and gas pipelines, petrochemical refineries, power plants, shipbuilding, and municipal water systems. Their ability to withstand high pressure, thermal stress, and mechanical loads makes them perfect for boiler piping, steam distribution lines, process industries, and fire protection systems. In water treatment and construction, carbon steel fittings offer a cost-effective and durable solution.
