Nguyen Fittings and Plates, located in Da Nang, Vietnam, is a well-respected manufacturer and supplier of top-notch **Inconel 625 Forged Fittings** that are built to withstand the toughest industrial conditions. These fittings are crafted to perform reliably even under extreme pressure, high temperatures, and corrosive environments. Utilizing cutting-edge forging technology, precise machining, and thorough testing, Nguyen Fittings guarantees that each piece offers exceptional strength, leak-proof functionality, and a long lifespan. Catering to industries like chemical processing, marine, aerospace, offshore oil and gas, and power generation, Nguyen Fittings delivers Inconel 625 Forged Fittings that meet international standards for safe and efficient use in demanding applications.
| Standards | ASTM, ASME |
| Designation | B564, SB564 |
| Dimension Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Grade | Inconel 625 Forged Fittings. |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Types of Forged Fittings | Elbow, Tee, Union, Cross, Swage Nipples, Coupling, CAP, Plug, Bush. |
Inconel 625 Forged Fittings are made from a nickel-chromium-molybdenum alloy that’s enhanced with niobium, providing remarkable mechanical properties. This alloy boasts impressive tensile and yield strength without needing heat treatment, along with excellent fatigue and creep resistance. It also offers outstanding corrosion resistance in both oxidizing and reducing environments, including seawater, acidic chemicals, and high-temperature oxidation. The blend of high strength, ductility, and toughness makes these fittings a reliable choice for high-pressure and high-temperature piping systems.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Nguyen Fittings is a leading supplier of Inconel 625 Forged Fittings in Da Nang, Vietnam. We offer an extensive range of Inconel 625 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Choose Inconel 625 Forged Fittings from Nguyen Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Inconel 625 Forged Fittings offer exceptional advantages, including high strength, excellent corrosion resistance, and superior performance in extreme conditions. Their ability to resist pitting, crevice corrosion, and stress corrosion cracking makes them ideal for marine, chemical, and offshore applications. These fittings maintain mechanical integrity at elevated temperatures, providing outstanding thermal-fatigue and oxidation resistance. Inconel 625’s excellent weldability allows for ease of installation and customization. With their durability and resistance to harsh environments, these fittings deliver long-lasting, reliable solutions for industries such as aerospace, power generation, and petrochemical processing.
Yes, custom sizes for Inconel 625 Forged Fittings are available at Nguyen Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@nguyenfittings.com
These fittings are widely utilized in industries that require strong and corrosion-resistant connections. You’ll often find them in offshore platforms, marine engineering, chemical plants, aerospace propulsion systems, heat exchangers, nuclear reactors, and pollution-control equipment. They are designed to handle highly corrosive fluids, exposure to seawater, and extreme thermal cycling without losing their structural integrity. Their ability to maintain dependable performance under severe mechanical and chemical stresses truly sets them apart.
