Nguyen Fittings and Plates supplies high-purity Nickel Alloy 201 Forged Fittings for enhanced corrosion resistance and electrical conductivity. Fabricated as per ASTM B564 and ASME B16.11 specifications, these socket weld and threaded fittings are applicable in caustic environments, food-grade systems, and high-purity applications. Stamped with strength and accuracy, Nickel 201 fittings are used in applications that require non-magnetic components with low carbon content. Nguyen provides close dimensional tolerance, clean finishes, and conformity to international standards of quality.
Specifications : ASTM B564 / ASTM SB 564
Type : Socketweld Fittings, Screwed-Threaded Fittings
Size : ⅛” to 4”
Class :2000 LBS, 3000 LBS, 6250 LBS, 9000 LBS
Standards : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Nickel Alloy 201 has more than 99.6% pure nickel with extremely low carbon (≤0.02%), which makes it the best fit for applications where brittleness due to carbon cannot be tolerated. It exhibits a tensile strength of 380–520 MPa and yield strength of approximately 100–160 MPa, with superior thermal and electrical conductivity. It is resistant to caustic alkalis, salts, and weak acids, and maintains ductility under both hot and cold work conditions. Nickel 201 is in a non-magnetic state when in the annealed condition and is readily fabricable or weldable.
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Nguyen Fittings is a leading supplier of Nickel Alloy 201 Forged Fittings in Da Nang, Vietnam. We offer an extensive range of Nickel Alloy 201 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Density (Kg.m-1) | 84.3 |
|---|---|
| Magnetic Permeability (20°C) | <1.005 |
| Curie Temperature (°C) | -90 |
| Young’s Modulus (N/mm2) | 179 x 103 |
| Specific Heat, 20°C (J.Kg-1.°K-1) | 418 |
| Specific Electrical Resistance, 20°C (?O.m) | 0.62 |
| Thermal conductivity,20°C (W.m-1.°K-1) | 17.5 |
| Mean coefficient of thermal expansion, 20-100°C (°K-1) | 13.4 x 10-6 |
| STANDARD | WERKSTOFF NR. | UNS | AFNOR | GOST | JIS | BS | EN | OR |
| Nickel 201 | 2.4068 | N02201 | – | НП-2 | NW 2201 | NA 12 | LC-Ni 99 | – |
Nickel Alloy 201 Forged Fittings from Nguyen Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 201 Forged Fittings offer remarkable advantages, including excellent corrosion resistance in reducing and neutral environments, making them ideal for chemical and marine applications. Their low carbon content minimizes carbide precipitation, enhancing performance in high-temperature and caustic environments. These fittings exhibit exceptional thermal and electrical conductivity, ensuring efficiency in heat exchangers and electronic systems. With excellent mechanical strength, ductility, and weldability, they are easy to fabricate and maintain. Nickel Alloy 201 resistance to stress corrosion cracking and oxidation ensures reliable, long-term performance, even in harsh operational conditions, across various industries.
Yes, custom sizes for Nickel Alloy 201 Forged Fittings are available at Nguyen Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@nguyenfittings.com.
Nickel 201 forged fittings find application in electroplating, chemical handling, food processing, marine systems, and battery manufacturing. Due to their purity, they are best suited for high-temperature alkali service, electronic components, and synthetic fiber manufacture. They are suitable for use in heat exchangers, caustic evaporators, and condenser systems where contamination is not acceptable. They provide excellent corrosion resistance and long life when used in chemical and industrial processes with alkaline solutions, organic compounds, and salts.4. Hastelloy Pipe Fittings
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
