Monel Forged Fittings Manufacturer and Supplier in Da Nang, Vietnam

Nguyen Fittings and Plates has a complete range of Monel Forged Fittings. These are perfect for applications in highly corrosive, saltwater, and acidic conditions. Manufactured under ASTM B564 and ASME B16.11, our Monel forged fittings come in socket weld and threaded types, made from Monel 400 and Monel K500 grades. Known for their high nickel content, these fittings offer excellent resistance to seawater, hydrofluoric acid, and chloride stress corrosion. Monel forged fittings are crucial in marine systems, chemical industries, and hydrocarbon processing plants where corrosion resistance and mechanical strength are vital.

Monel Forged Fittings Price List in Da Nang, Monel Forged Fittings Supplier in Hue, Monel Forged Fittings Exporter in Hanoi, Monel Forged Fittings Supplier in Hanoi, Monel Forged Fittings Exporter in Sapa, Monel Forged Fittings Size Chart, Monel Forged Fittings Price in Ho Chi Minh, Monel Forged Fittings in Da Nang, Monel Forged Fittings Supplier in Vietnam, Monel Forged Fittings Stockist in Hue, Monel Forged Fittings Exporter in Vietnam

Monel Forged Fittings Specification

Specifications : ASTM B564 & ASME SB564

Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799

Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)

Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

Type : Socketweld Fittings, Screwed-Threaded Fittings

Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)

Monel forged fittings are made up of nickel (63–70%), copper (28–34%), and trace elements like iron, manganese, and silicon. Monel 400 provides a tensile strength of about 550 MPa and a yield strength of around 240 MPa, while Monel K500 offers even higher strength through age hardening. These fittings have high impact resistance, dimensional stability, and excellent corrosion resistance, especially in marine, acidic, and alkaline environments. They maintain their strength and integrity even at cryogenic and elevated temperatures.

Monel Forged Fittings Chemical Compostion

Grade	C	Mn	Si	S	Cu	Fe	Ni
Monel 400	0.30 max	2.00 max	0.50 max	0.024 max	28.00 – 34.00	2.50 max	63.00 min
Monel K500	0.25 max	1.5 max	0.5 max	0.010 max	27.00 – 33.00	0.5 – 2	63.00 min

Monel Forged Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Monel 400	8.8 g/cm3	1350 °C (2460 °F)	Psi – 80,000 , MPa – 550	Psi – 35,000 , MPa – 240	40 %
Monel K500	8.44 g/cm3	1350 °C (2460 °F)	Psi – 160000 , MPa – 1100	Psi – 115000 , MPa – 790	20 %

Monel Forged Fittings Exporter in Vietnam, Monel Forged Fittings Price List in Da Nang, Monel Forged Fittings Supplier in Hue, Monel Forged Fittings Exporter in Hanoi, Monel Forged Fittings Exporter in Sapa, Monel Forged Fittings in Ho Chi Minh, Monel Forged Fittings Size Chart, Monel Forged Fittings Price in Ho Chi Minh, Monel Forged Fittings Weight Chart, Monel Forged Fittings Supplier in Vietnam, Monel Forged Fittings Stockist in Hue

Largest Monel Forged Fittings Supplier in Da Nang, Vietnam

Nguyen Fittings is a leading supplier of Monel Forged Fittings in Da Nang, Vietnam. We offer an extensive range of Monel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Monel Forged Fittings Equivalent Grade

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Monel	2.4360	N04400	NW 4400	NA 13	МНЖМц 28-2,5-1,5	NU-30M	NiCu30Fe

Why Choose Monel Forged Fittings from Nguyen Fittings?

Choose Monel Forged Fittings from Nguyen Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.

Monel Forged Fittings Exporter in Hue, Monel Forged Fittings Sizes in mm, Monel Forged Fittings Manufacturer in Hanoi, Monel Forged Fittings Thickne Alloy Steel Weld Neck, Monel Forged Fittings Supplier in Da Nang, Monel Forged Fittings Price List in Vietnam, Monel Forged Fittings Distributor in Sapa, Monel Forged Fittings Supplier in Hanoi, Monel Forged Fittings Distributor in Vietnam

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Monel Forged Fittings offer several key advantages, including exceptional corrosion resistance, particularly in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions, such as marine and chemical processing applications. Monel fittings maintain their strength and integrity at elevated temperatures, offering superior durability in high-stress environments. They also possess excellent weldability and machinability, making installation and customization easier. With their long-lasting performance and ability to withstand extreme conditions, Monel Forged Fittings provide reliable solutions for critical industrial applications.

Types of Monel Forged Fittings

Are Custom Sizes Available for Monel Forged Fittings?

Yes, custom sizes for Monel Forged Fittings are available at Nguyen Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@nguyenfittings.com

Monel Forged Fittings Supplier in Da Nang, Monel Forged Fittings Weight Chart, Monel Forged Fittings Exporter in Hue, Monel Forged Fittings Manufacturer in Hanoi, Monel Forged Fittings Price List in Vietnam, Monel Forged Fittings Sizes in mm, Monel Forged Fittings Distributor in Sapa, Monel Forged Fittings in Ho Chi Minh, Monel Forged Fittings Distributor in Vietnam

Application Industry of Monel Forged Fittings

Monel forged fittings are widely used in marine engineering, chemical processing, power plants, brine systems, pumps, and valves. They are suitable for systems that transport seawater, hydrofluoric acid, or salt-based chemicals. Applications include heat exchangers, marine hardware, oil rigs, fuel tanks, and chlorinated solvent systems. These fittings provide great performance under pressure, temperature, and corrosive stress, ensuring a long service life and minimizing the need for frequent maintenance or replacement in demanding industrial settings.
