Nguyen Fittings and Plates, located in Da Nang, Vietnam, stands out as a reliable manufacturer and supplier of top-notch **ASTM A860 WPHY 80 Pipe Fittings** tailored for high-pressure piping systems. These fittings are crafted to deliver outstanding strength, toughness, and dependability in the demanding fields of oil, gas, petrochemicals, and power generation. Utilizing cutting-edge forging, forming, and heat-treatment techniques while strictly following international standards, Nguyen Fittings guarantees precise dimensions, leak-proof performance, and a long lifespan. By merging quality craftsmanship with strong material choices, they provide WPHY 80 fittings that ensure safety, efficiency, and durability in critical industrial settings.
| Specifications | ASTM A860 / ASME SA860 |
|---|---|
| Size | 1/8” NB TO 48” NB. |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Type | Seamless / Welded / Fabricated |
| Thickness | Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS |
Made from high-strength, low-alloy steel, ASTM A860 WPHY 80 Pipe Fittings boast impressive tensile and yield strength, along with remarkable impact resistance and toughness, even in chilly conditions. This alloy ensures reliable performance under high internal pressures and maintains its structural integrity through temperature changes and mechanical stress. Designed to withstand corrosive and abrasive substances, these fittings promise long-term operation without sacrificing safety or efficiency in harsh industrial environments.
| Grade | C | Mn | P | S | Si | Ni | Cr | Mo | Cu | Ti | V | Cb | Al |
| A860 WPHY 80 | 0.20 | 1.001-1.45 | 0.03 | 0.01 | 0.15-0.40 | 0.50 | 0.30 | 0.25 | 0.35 | 0.05 | 0.10 | 0.04 | 0.06 |
| Grade | Tensile Strenght | Yield Strenght, min. |
| A860 WPHY 80 | 66 Ksi | 52 Ksi |
Nguyen Fittings is a leading supplier of ASTM A860 WPHY 80 Pipe Fittings in Da Nang, Vietnam. We offer an extensive range of ASTM A860 WPHY 80 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose ASTM A860 WPHY 80 Pipe Fittings from Nguyen Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
ASTM A860 WPHY 80 Pipe Fittings offer exceptional advantages, including superior strength and durability, with a tensile strength of 860 MPa and a yield strength of 590 MPa. They provide excellent resistance to corrosion, impact, and wear, making them ideal for harsh environments, including offshore and high-pressure applications. These fittings are designed to perform reliably in low-temperature conditions and high-stress systems. Their robust construction ensures long-lasting, leak-proof connections, reducing maintenance and downtime. ASTM A860 WPHY 80 fittings are perfect for critical applications in industries such as oil, gas, petrochemicals, and power generation.
Yes, custom sizes for ASTM A860 WPHY 80 Pipe Fittings are available at Nguyen Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@nguyenfittings.com
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
You’ll find ASTM A860 WPHY 80 Pipe Fittings commonly used in oil and gas transmission pipelines, chemical processing facilities, refineries, offshore and onshore drilling operations, and power generation plants. They’re perfect for high-pressure piping systems that demand secure, leak-proof connections and lasting durability. With their strength, resistance to mechanical fatigue, and compatibility with welding processes, these fittings are vital for safely transporting hydrocarbons, steam, and other essential process fluids. They play a crucial role in ensuring the reliability and efficiency of complex infrastructure systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
